SG18-08NOF

High temperature proximity sensor

Model SG18-08NCF Output type NPN Normally open, flush size M18 Detection distance 8mm±10% Housing material Nickel-copper alloy Operating voltage 10~30VDC(Ripple< 10%) pressure drop < 1.5V load current 200mA no-load current < 10mA leakage current 0.01mA switching frequency 500HZ repetition accuracy < 3.0%(Sr) hysteresis < 15%(Sr) induction surface material PBT ambient temperature -25~+120℃ protection class IP67
SG18-05NCF

High temperature proximity sensor

Model SG18-05NCF Output type NPN normally closed, flush size M18 Detection distance 5mm±10% Housing material Nickel-copper alloy Operating voltage 10~30VDC(Ripple< 10%) pressure drop < 1.5V load current 200mA no-load current < 10mA leakage current 0.01mA switching frequency 1KHZ repetition accuracy < 3.0%(Sr) hysteresis < 15%(Sr) induction surface material PBT ambient temperature -25~+120℃ protection class IP67
SG18-08NCF

High temperature proximity sensor

Model SG18-08NCF Output type NPN normally closed, flush size M18 Detection distance 8mm±10% Housing material Nickel-copper alloy Operating voltage 10~30VDC(Ripple< 10%) pressure drop < 1.5V load current 200mA no-load current < 10mA leakage current 0.01mA switching frequency 500HZ repetition accuracy < 3.0%(Sr) hysteresis < 15%(Sr) induction surface material PBT ambient temperature -25~+120℃ protection class IP67
SG18-08NON

High temperature proximity sensor

Model SG18-08NON Output type NPN Normally open, non-flush size M18 Detection distance 8mm±10% Housing material Nickel-copper alloy Operating voltage 10~30VDC(Ripple< 10%) pressure drop < 1.5V load current 200mA no-load current < 10mA leakage current 0.01mA switching frequency 500HZ repetition accuracy < 3.0%(Sr) hysteresis < 15%(Sr) induction surface material PBT ambient temperature -25~+120℃ protection class IP67
SG18-12NON

High temperature proximity sensor

Model SG18-12NON Output type NPN Normally open, non-flush size M18 Detection distance 12mm±10% Housing material Nickel-copper alloy Operating voltage 10~30VDC(Ripple< 10%) pressure drop < 1.5V load current 200mA no-load current < 10mA leakage current 0.01mA switching frequency 150HZ Repetition accuracy < 3.0%(Sr) hysteresis < 15%(Sr) induction surface material PBT ambient temperature -25~+120℃ protection class IP67
SG18-08NCN

High temperature proximity sensor

Model SG18-08NCN Output type NPN normally closed, non-flush size M18 Detection distance 8mm±10% Housing material Nickel-copper alloy Operating voltage 10~30VDC(Ripple< 10%) pressure drop < 1.5V load current 200mA no-load current < 10mA leakage current 0.01mA switching frequency 500HZ repetition accuracy < 3.0%(Sr) hysteresis < 15%(Sr) induction surface material PBT ambient temperature -25~+120℃ protection class IP67
SG18-12NCN

High temperature proximity sensor

Model SG18-12NCN Output type NPN normally closed, non-flush size M18 Detection distance 12mm±10% Housing material Nickel-copper alloy Operating voltage 10~30VDC(Ripple< 10%) pressure drop < 1.5V load current 200mA no-load current < 10mA leakage current 0.01mA switching frequency 150HZ Repetition accuracy < 3.0%(Sr) hysteresis < 15%(Sr) induction surface material PBT ambient temperature -25~+120℃ protection class IP67
SG30-10NOF

High temperature proximity sensor

Model SG30-10NOF Output Type NPN Normally open, flush size M30 Detection distance 10mm±10% Housing material Nickel-copper alloy Operating voltage 10~30VDC(Ripple< 10%) pressure drop < 1.5V load current 200mA no-load current < 10mA leakage current 0.01mA switching frequency 300HZ Repetition accuracy < 3.0%(Sr) hysteresis < 15%(Sr) induction surface material PBT ambient temperature -25~+120℃ protection class IP67
SG30-15NOF

High temperature proximity sensor

Model SG30-15NOF Output Type NPN Normally open, flush size M30 Detection distance 15mm±10% Housing material Nickel-copper alloy Operating voltage 10~30VDC(Ripple< 10%) pressure drop < 1.5V load current 200mA no-load current < 10mA leakage current 0.01mA switching frequency 150HZ Repetition accuracy < 3.0%(Sr) hysteresis < 15%(Sr) induction surface material PBT ambient temperature -25~+120℃ protection class IP67
