PRC4Y10

Ordinary optical fiber

Model PRC4Y10 Detection Form Reflective Detection Distance 60mm Thread Specification M4 Thread Length 15mm Fiber Outer Diameter Φ 1.3 Fiber core diameter Φ 0.5/ Φ 0.25x9 working temperature -50 ℃~+70 ℃ bending radius R15 protection level IP67
PRC6Y10

Ordinary optical fiber

Model PRC6Y10 Detection Form Reflective Detection Distance 140mm Thread Specification M6 Thread Length 15mm Fiber Outer Diameter Φ 2.2 Fiber core diameter Φ 1.0/ Φ 0.25x16 working temperature -50 ℃~+70 ℃ bending radius R25 protection level IP67
PRC6Y10-I

Ordinary optical fiber

Model PRC6Y10/20-I detection form Reflective detection distance 180mm Thread specification M6 Thread length 15mm Fiber outer diameter Φ 2.2 Fiber core diameter Φ 1.0/ Φ 0.25x16 working temperature -50 ℃~+70 ℃ bending radius R25 protection level IP67
PRS3Y10-I

Ordinary optical fiber

Model PRS3Y10/20-I detection form Reflective detection distance 50mm Thread specification M3 Thread length 12mm Optical fiber outer diameter Φ 1.0 core diameter Φ 0.5 working temperature -50 ℃~+70 ℃ bending radius R15 protection level IP67
PRS4Y10

Ordinary optical fiber

Model PRS4Y10/20 detection form Reflective detection distance 50mm Thread specification M4 Thread length 12mm Fiber outer diameter Φ 1.0 core diameter Φ 0.5 working temperature -50 ℃~+70 ℃ bending radius R15 protection level IP67
PT4Y10

Ordinary optical fiber

Model PT4Y10/20 detection form Reflective detection distance 1000mm Thread specification M4 Thread length 12mm Fiber outer diameter Φ 2.2 Fiber core diameter Φ 1.0 Working temperature -50 ℃~+70 ℃ Bending radius R25 Protection level IP67
PT6Y10

Ordinary optical fiber

Model PT6Y10/20 detection form: opposite detection distance 1000mm, thread specification M6, thread length 12mm, optical fiber outer diameter Φ 2.2 Fiber core diameter Φ 1.0 Working temperature -50 ℃~+70 ℃ Bending radius R25 Protection level IP67
PTS3Y10

Ordinary optical fiber

Model PTS3Y10/20 detection form: opposite detection distance: 260mm, thread specification: M3, thread length: 15mm, optical fiber outer diameter: Φ 1.0 core diameter Φ 0.5 working temperature -50 ℃~+70 ℃ bending radius R15 protection level IP67
PTS4Y10

Ordinary optical fiber

Model PTS4Y10/20 detection form: detection distance of 260mm, thread specification: M4, thread length: 15mm, optical fiber outer diameter Φ 1.0 core diameter Φ 0.5 working temperature -50 ℃~+70 ℃ bending radius R15 protection level IP67
