| Model | ER2-18ZW-V |
|---|---|
| Output type | NPN output |
| Detection method | Diffuse reflection, through-beam (determined by fiber type) |
| Detection distance | Standard: diffuse reflection 200mm, through-beam 700mm Long distance: diffuse reflection 300mm, through-beam 1200mm |
| Output status | Normally open/normally closed switchable |
| Reaction time | High speed: less than 100us Standard: less than 500us Long distance: less than 3ms |
| Protection circuits | Power supply polarity reverse polarity protection; Output short-circuit or overload protection |
| Output delay | Normal output/output extension/delayed output/primary output, four output modes are optional |
| Supply voltage | 12-24DC±10%, floating P-P 10% or less |
| Light source | Red, 4-element light-emitting diode body |
| Consumes current | Less than 30mA |
| Ambient temperature | -25 to +55°C, no freezing |
Amplifier type: Chinese fiber amplifier
Features: Full Chinese panel display, one-key quick setting, quick response
Product advantage: Detection of fast-moving small parts with functions such as background elimination/automatic maintenance
