| Model | NPN | BGL-235NZ |
NPN+ analog | BGL-235NMZ | |
| NPN+RS485 | BGL-235NZ -485 | |
| Detection method | diffuse reflection | |
| Datum (center) distance | 235mm | |
Measuring range (F.S.) | 35~435m | |
| Full scale | 400mm | |
| Repeatability | 35-135mm:0.1mm 135-235mm:0.3mm 235-335mm:0.8mm 335-500mm:1.5mm | |
| Linear accuracy | 35-135mm:0.1mm 135-235mm:0.3mm | |
| Temperature drift characteristics | ±0.03F.S./℃ | |
| light source | medium | Red diode laser, wavelength 655nm |
| Output power | ＜1mW | |
| Laser class | IEC Class 2 | |
| Spot diameter | 35mm:3mm 135mm:1mm 235mm:0.5mm 335mm:0.5mm 435mm:2mm | |
| output | Switching amount | NPN collector open, ≤50mA/DC 24V, residual voltage <1.5V |
| Analogue | Analog voltage: 0~5V (alarm: 5.2V); analog current: 4~20mA (alarm: 0mA), Chinese display can be switched | |
| Output actions | Light.on (light entry action) / Dark.on (shading action) can be selected | |
| Response time | 1.5ms/5ms/10ms, switchable | |
| Operating voltage | DC 12~24V ±10% | |
| Consume (no-load) current | <30mA (at 24V DC supply voltage), <60mA (at 12V DC with supply voltage) | |
| Light | Output indicator: yellow; Power LED: Green | |
| Ambient illumination | Incandescent ≤ 3000Lux; Sunlight ≤ 200Lx | |
| Ambient temperature | Working time: -10°C~45°C; Storage: -20°~60 (no freezing) | |
| 環境濕度 | 工作時:35%~85%RH;存儲時:35%~85%RH(無凝結) | |
| 保護電路 | 極性反接保護/浪涌保護/短路保護 | |
| 保護等級 | IP67 | |
| 耐電壓 | AC1000V,50/60Hz,1min | |
| 耐振動 | 10~55Hz(周期1分鐘)，雙振幅1.5mm，X/YZ方向各2H | |
| 耐沖擊 | 500m/s(約50G)XYZ各方向3次 | |
| 絕緣阻抗 | 50MΩ以上(DC500V兆歐表) | |
| 材質 | 外殼 | 鋁合金 |
| 鏡片 | PMMA | |
| 導線 | PVC(聚氯乙烯) | |
| 連接方式 | 開關量:導線引出型(4芯，標準線長2米);模擬量:導線引出型(5芯，標準線長2米) | |
| 包裝重量 | 約85g(含線) | |
Features: diffuse reflection, Chinese operation interface, small size/small light spot/multiple detection modes optional
Detection distance: 35~435mm
Output mode: NPN, NPN+ analog, NPN+RS485
