Model | TS-089P |
---|---|
Operating voltage | 5~24V DC |
Output mode | PNP is normally open |
Repeatability | 0.001mm |
itinerary | 3mm |
Operating force | 0.6N |
Displacement before action | 0.5~09mm |
Backdrop | 0.1mm |
Frequency of action | 120 times/min |
Output current | 10mA |
Consumes current | 10mA |
Light | The light is on when output |
Compressive strength | AC1000V, 1 minute |
Dielectric strength | 250V DC>=20MQ |
Ambient temperature and humidity | 20~85°C (no freezing), 20%~95%RH (non-condensing) |
Degree of protection | IP67 |
Output mode: PNP normally open
Stroke: 3mm
Repeatability: 0.001mm
